Applications
1.25Gb/s 1000Base-SX Ethernet Links
1x Fiber Channel
High speed I/O for file servers
Switch to Switch interface
Distributed multi-processing
Channel extender, Data storage
Product Features
Compliant with specifications for SFP MSA standard
Compliant with specifications for IEEE-802.3z Gigabit Ethernet Standard
Compliant with specifications for SDH/SONET/ATM standard
Duplex LC Connector
850nm Oxide VCSEL laser transmitter
Differential LVPECL inputs and outputs
Compliant with ANSI specifications for Fiber Channel applications at 1.0625Gbps
TTL signal detect indicator
Up to 1.25Gb/s bi-directional data links, NRZ
Single Power Supply 3.3V
Hot-Pluggable SFP footprint
Distance up to 500m on 50/125μm MMF, 300m on 62.5/125μm MMF
Metal enclosure for lower EMI
Extended operation temperature range: 0℃ to 70℃
Order Information
Part Number |
Compatible Finisar P/N |
Description |
SLS2850-NT |
AA1419013 |
1.25Gbps LC MMF 850nm VSCEL, 550m |
SLS2130-NT |
AA1419015 |
1.25Gbps LC SMF 1310nm FP/PIN, 10km |
SLS2150-NT |
AA1419016 |
1.25Gbps LC SMF 1550nm DFB/PIN, 70km |
|
|
|
