Product Features:
Support GE and 10G Ethernet applications
XENPAK-10GB-ER 1550nm EML and PIN receiver
SFI high speed electrical interface
2-wire interface with integrated Digital Diagnostic monitoring for optional
XENPAK MSA package with duplex SC connector
Single +3.3V power supply
Power consumption less than 1.0W
Operating case temperature: 0~+70°C
Compatible with IEEE802.3ae, IEEE802.3ak, IEEE802.3aq standards
Hot-swappable input/output device
Plugs into an Ethernet XENPAK port of a switch or router to link the port with the network
Compliance standard
Feature |
Standard |
Performance |
Electrostatic Discharge
(ESD) to the Electrical Pins |
MIL-STD-883E
Method 3015.7 |
Class 1(>1000V for SFI pins, >2000V for other pins.) |
Electrostatic Discharge (ESD) to the Duplex LC Receptacle |
IEC 61000-4-2
GR-1089-CORE |
Compatible with standards |
Electromagnetic
Interference (EMI) |
FCC Part 15 Class B
EN55022 Class B (CISPR 22B)
VCCI Class B |
Compatible with standards |
Immunity |
IEC 61000-4-3 |
Compatible with standards |
Laser Eye Safety |
FDA 21CFR 1040.10 and 1040.11
EN60950, EN (IEC) 60825-1,2 |
Compatible with Class I laser product. |
Specifications / Ordering Information:
XENPAK-10GB-SR |
Package: XENPAK
Date Rate: 10.3Gbps
Wavelength: 850nm
TX optic Power: -7.3~-1.2dBm
RX sensitivity: <-9.9dBm
Operate Temp: 0~70℃
VCSEL and PIN, MMF SC
Reach: 300m |
XENPAK-10GB-LR |
Package: XENPAK
Date Rate: 10.3Gbps
Wavelength: 1310nm
TX optic Power: -8~0.5dBm
RX sensitivity: <-12.6dBm
Operate Temp: 0~70℃
DFB and PIN, SMF SC
Reach: 10km |
XENPAK-10GB-ER |
Package: XENPAK
Date Rate: 10.3Gbps
Wavelength: 1550nm
TX optic Power: -4.7~+4.0dBm
RX sensitivity: <-15.8dBm
Operate Temp: 0~70℃
DFB and PIN, SMF SC
Reach: 40km |
|
