FMC-FEBD(S) Series Copper to Fiber Media Converter Single fiber converter adopt WDM technique, so transmitting and receiving on one same roof of fiber and save fiber consumption can be wide use on limited fiber resource, rent other people’s fiber optic or two cores fibers to have one breakdown of an emergence situation .It is excellent product for broadband long distance transmit. The FMC-FEBD13-S60 is 10/100M auto negotiation, standalone single fiber media converter, distance upto 60km.
Specification:
1) Support IEEE802.3 10 Bases-Ts, IEEE802.3u 100 Bases- TX( UTP),100 Bases-FX( fiber) protocol
2) Full-duplexes, half duplex auto negotiation
3) Single mode TX1310nm/RX1550nm, SC or LC connector for option.
4) Transmitting distance upto 60km .
5) TP Line: double twist- wire: NODE\ HUB or SWITCH (5 UTP)
6) Indication light :PWR( power supply)TXL( TX port)SPD(TX port speed rate)FDX(TX port double duplex situation)RX(FX port receiving situation)FXL (FX connection situation)
7) The 10/100M media converter cards can realize Max.2046bytes packet at store-and-forward mode, Max. 9K bytes packet at cut-through mode
8) Auto MDI/MDIX provides automatic cross
9) Supporting remote and local management
Features
* Media converter card supports protocols like Q-in-Q Double Tag VLAN, IEEE802.1q Tag VLAN and IEEE802.3x Flow control
* Supporting Link Loopback test,
* Support protocol
IEEE802.3 fast Ethernet (10 Mbps)
IEEE802.3u Fast ether net(100 Mbps) IEEE802.3x full duplex flow control
IEEE802.1d spanning tree protocol
IEEE802.1Q VLAN remark protocol
IEEE802.1p QOS PRI protocol
Other parameter
Size: 150mmX115mmX38mm Weight:0.854Kg
Power supply:100 V~275 VAC 50~60 Hz
Work temperature:0 ℃~60℃ store temperature:-10 ℃ ~70 ℃
Humidity:5%~95% (no condensation)
APPLICATION:
Order Information
|
FMC-FEBD13-C25 |
2U Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,25km,SC LFP |
|
FMC-FEBD15-C25 |
2U Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,25km,SC LFP |
|
FMC-FEBD13-C25M |
2U Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,25km,SC LFP,SNMP |
|
FMC-FEBD15-C25M |
2U Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,25km,SC LFP,SNMP |
|
FMC-FEBD13-C40 |
2U Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,40km,SC LFP |
|
FMC-FEBD15-C40 |
2U Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,40km,SC LFP |
|
FMC-FEBD13-C40M |
2U Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,40km,SC LFP,SNMP |
|
FMC-FEBD15-C40M |
2U Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,40km,SC LFP,SNMP |
|
FMC-FEBD13-C60 |
2U Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,60km,SC LFP |
|
FMC-FEBD15-C60 |
2U Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,60km,SC LFP |
|
FMC-FEBD13-C60M |
2U Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,60km,SC LFP,SNMP |
|
FMC-FEBD15-C60M |
2U Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,60km,SC LF,SNMP |
|
FMC-FEBD13-C80 |
2U Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,80km,SC LFP |
|
FMC-FEBD15-C80 |
2U Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,80km,SC LFP |
|
FMC-FEBD13-C80M |
2U Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,80km,SC LFP,SNMP |
|
FMC-FEBD15-C80M |
2U Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,80km,SC LFP,SNMP |
|
FMC-FEBD13-S25 |
STD Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,25km,SC LFP,96~230VAC |
|
FMC-FEBD15-S25 |
STD Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,25km,SC LFP,96~230VAC
|
|
FMC-FEBD13-S25M |
STD Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,25km,SC LFP,96~230VAC,SNMP |
|
FMC-FEBD15-S25M |
STD Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,25km,SC LFP,96~230VAC,SNMP |
|
FMC-FEBD13-S40 |
STD Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,40km,SC LFP,96~230VAC |
|
FMC-FEBD15-S40 |
STD Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,40km,SC LFP,96~230VAC |
|
FMC-FEBD13-S40M |
STD Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,40km,SC LFP,96~230VAC,SNMP |
|
FMC-FEBD15-S40M |
STD Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,40km,SC LFP,96~230VAC,SNMP |
|
FMC-FEBD13-S60 |
STD Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,60km,SC LFP,96~230VAC |
|
FMC-FEBD15-S60 |
STD Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,60km,SC LFP,96~230VAC |
|
FMC-FEBD13-S60M |
STD Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,60km,SC LFP,96~230VAC,SNMP |
|
FMC-FEBD15-S60M |
STD Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,60km,SC LFP,96~230VAC,SNMP |
|
FMC-FEBD13-S80 |
STD Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,80km,SC LFP,96~230VAC |
|
FMC-FEBD15-S80 |
STD Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,80km,SC LFP,96~230VAC |
|
FMC-FEBD13-S80M |
STD Bidi |
10/100Mbps,SMF1310nmTX/1550nmRX,80km,SC LFP,96~230VAC,SNMP |
|
FMC-FEBD15-S80M |
STD Bidi |
10/100Mbps,SMF1550nmTX/1310nmRX,80km,SC LFP,96~230VAC,SNMP |
|
