| SLS8519D-FNS |
 |
|
|
|
|
Features |
|
1000Base-SX, upto 2.125Gbps
DDM support, 550m MMF
Compatible Finisar FTRJ8519P1BNL
|
|
|
|
| Description |
|
|
Applications
1.25Gb/s 1000Base-SX Ethernet Links
1x or 2x Fiber Channel
High speed I/O for file servers
Switch to Switch interface
Distributed multi-processing
Channel extender, Data storage
Product Features
Compliant with specifications for SFP MSA standard
Compliant with specifications for IEEE-802.3z Gigabit Ethernet Standard
Compliant with specifications for SDH/SONET/ATM standard
Duplex LC Connector
Built-in digital diagnostic functions
850nm Oxide VCSEL laser transmitter
Differential LVPECL inputs and outputs
Compliant with ANSI specifications for Fiber Channel applications at 1.0625Gbps
TTL signal detect indicator
Up to 2.125Gb/s bi-directional data links, NRZ
Single Power Supply 3.3V
Hot-Pluggable SFP footprint
Distance up to 500m on 50/125μm MMF, 300m on 62.5/125μm MMF
Metal enclosure for lower EMI
Extended operation temperature range: 0℃ to 70℃
Order Information
|
Part Number |
Compatible Finisar P/N |
Description |
|
SLS8519(D)-FNS |
FTRJ8519P1BNL |
2Gbps LC MMF 850nm VSCEL, 550m DDM option |
|
SLS1319(D)-FNS |
FTRJ1319P1BTL |
2Gbps LC SMF 1310nm FP/PIN, 10km DDM option |
|
SLS1519(D)-FNS |
FTRJ1519P1BCL |
2Gbps LC SMF 1550nm DFB/PIN, 70km DDM option |
|
SLS1621(D)-FNS |
FTRJ1621P1BCL |
2Gbps LC SMF 1550nm DFB/APD, 100km DDM option |
|
| Part Number |
Package |
Application |
Com-MFR |
Comp-P/N |
Parameters |
| SLS8519D-FNS |
SFP |
GE,FC2,OC-48 |
FINISAR |
FTRJ8519P1BNL |
2.5Gb/s,850nmVCSEL/PIN,MMF LC 500m,0~70℃,3.3V DDM |
|
|
