Applications
1.25Gb/s 1000Base-ZX Ethernet Links
1x or 2x Fiber Channel
High speed I/O for file servers
Switch to Switch interface
Distributed multi-processing
Channel extender, Data storage
Product Features
Compliant with specifications for SFP MSA standard
Compliant with specifications for IEEE-802.3z Gigabit Ethernet Standard
Compliant with specifications for SDH/SONET/ATM standard Duplex LC Connector Built-in digital diagnostic functions
1550nm DFB laser transmitter
Differential LVPECL inputs and outputs
Compliant with ANSI specifications for Fiber Channel applications at 1.0625Gbps
TTL signal detect indicator
1.25Gb/s bi-directional data links, NRZ
Single Power Supply 3.3V
Hot-Pluggable SFP footprint Distance up to 80km on 9/125μm SMF Metal enclosure for lower EMI Extended operation temperature range: 0℃ to 70℃
Order Information
Part Number |
Compatible Finisar P/N |
Description |
SLS8519(D)-FNS |
FTRJ8519P1BNL |
2Gbps LC MMF 850nm VSCEL, 550m DDM option |
SLS1319(D)-FNS |
FTRJ1319P1BTL |
2Gbps LC SMF 1310nm FP/PIN, 10km DDM option |
SLS1519(D)-FNS |
FTRJ1519P1BCL |
2Gbps LC SMF 1550nm DFB/PIN, 80km DDM option |
SLS1621(D)-FNS |
FTRJ1621P1BCL |
2Gbps LC SMF 1550nm DFB/APD, 100km DDM option |
|
